Power Divider/Combiner Assemblies

JFW’s online power divider/combiner assembly models are listed in the table below.

If you can’t find an online power divider/combiner assembly model to meet your requirements, please contact JFW at sales@jfwindustries.com.

Frequently Asked Questions

Click the column headers to sort our online models. For your specific application, please contact JFW for assistance or use our Inquiry Form.

JFW Model #ImpedanceConfigurationFrequency StartFrequency StopRF Input PowerRF Connectors
50PDA-03950 OhmsOne 12-Way Power Divider/Combiner800 MHz3000 MHz5 WattsN, SMA
50PDA-04050 OhmsOne 24-Way Power Divider/Combiner800 MHz3000 MHz5 WattsN, SMA
50PDA-07150 OhmsOne 8-Way Power Divider/Combiner (1U Panel)800 MHz2200 MHz5 WattsN
50PDA-09650 OhmsOne 4-Way Power Divider/Combiner (1U Panel)800 MHz2200 MHz5 WattsN
50PDA-09750 Ohm13 of 2-Way Power Dividers/Combiners, 2 of 8-Way Power Dividers/Combiners700 MHz3000 MHz5 WattsN
50PDA-15050 OhmsModular (2-Way, 4-Way, 8-Way)698 MHz3000 MHz5 WattsSMA

Power divider/combiner assemblies are typically used with custom RF test equipment. If you have a specific application for a power divider/combiner assembly, please send us a block diagram of your requirement. JFW does not change NRE’s for new power divider combiner assembly models. We pride ourselves in the ability to offer custom power divider/combiner models with the same pricing and delivery as our catalog power divider/combiner models.

Showing 1–3 of 6 results
