Sample GUI Test Programs

These sample programs differ from each other due to the different remote commands for each type of test system.  Along with each sample program is a description PDF file that goes through the functionality of each program.  If you have any questions or requests, please contact our engineering department directly at jfwengr@jfwindustries.com.

All remote command syntax used in our test programs can be found in the 3.X.X Firmware Manual.

Programmable Attenuator Assemblies:

50PA-xxx Sample Test Program
50PA-xxx Description

RF Switch Assemblies:

50SA-xxx Sample Test Program
50SA-xxx Description

Matrix Switches:

50MS-xxx Sample Test Program
50MS-xxx Description

Transceiver Test Systems:

50PMA-xxx Sample Test Program
50PMA-xxx Description

Below is a picture of the main window for the programmable attenuator sample test program. You can connect to the test system via Ethernet or RS-232 connection. All remote commands sent can be seen in the “Data Sent” window. All responses from the test system can be viewed in the “Data Received” window.
