RF Products for 5G Wireless Testing

The models listed below are several models that highlight our 5G product offering.  These models are also located on our standard sortable product tables.

The 5th generation of wireless mobile systems is being actively researched around the world by a multitude of companies.  Its high data rates will enable it to be much more than just the next generation of mobile networks.  It appears that 5G deployment will include frequency bands from sub-1 GHz to 6 GHz for mobile coverage and up to 50 GHz for the highest point to point transmission speeds.

RF Test Systems for 5G Wireless Testing

JFW Model #ImpedanceConfigdB TotaldB StepFrequency StartFrequency StopControlRF Connectors
50MS-36750 Ohms4 x 4 Blocking RF Matrix Switch0 MHz (DC)40 GHz2.92 mm
50PA-1002-XX50 Ohms1 to 16 Attenuators31 dB1 dB100 MHz40 GHzManual, Ethernet, RS-2322.92 mm
50PA-1019-XX50 Ohms1 to 16 Attenuators62 dB1 dB100 MHz40 GHzManual, Ethernet, RS-2322.92 mm
50BA-031-3150 Ohms2 Attenuators (Solid-State)31 dB1 dB100 MHz18 GHzManual, Ethernet, RS-232SMA
50BA-032-3150 Ohms4 Attenuators (Solid-State)31 dB1 dB100 MHz18 GHzManual, Ethernet, RS-232SMA

RF Switches for 5G Wireless Testing

JFW Model #ImpedanceSwitch ConfigSwitch TypeFrequency StartFrequency StopSwitching SpeedControlRF Connectors
50S-1634+XX50 Ohms1P6TNormally Open, Reflective0 MHz (DC)40 GHz20 mS+12, +15, +24, +28 Vdc2.9 mm
50S-1772+XX50 Ohms1P2TFailsafe, Reflective0 MHz (DC)40 GHz15 mS+12, +15, +24, +28 Vdc2.9 mm
50S-1773+XX50 Ohms1P4TNormally Open, Reflective0 MHz (DC)40 GHz20 mS+12, +15, +24, +28 Vdc2.9 mm

Programmable Attenuators for 5G Wireless Testing

JFW Model #ImpedancedB TotaldB StepFrequency StartFrequency StopSwitching SpeedControlRF Connectors
50P-210150 Ohms63.5 dB0.5 dB100 MHz18000 MHz1 uSTTLSMA
50P-210350 Ohms63 dB0.5 dB100 MHz18 GHz1 uSUSBSMA
50P-207250 Ohms31 dB1 dB100 MHz40 GHz0.5 uSTTL2.9 mm

Fixed Attenuators for 5G Wireless Testing

JFW Model #ImpedanceFrequency StartFrequency StopRF Input PowerAttenuation ValuesRF Connectors
50HFAR-XXX50 Ohms0 MHz (DC)40 GHz2 Watts3, 6, 10, 20, 30 dB2.9 mm
50HFAH-XXX50 Ohms0 MHz (DC)40 GHz0.5 Watts1, 2, 3, 6, 10, 20, 30 dB2.9 mm
50HFAT-XXX50 Ohms0 MHz (DC)50 GHZ0.5 Watts3, 6, 10, 20, 30 dB2.4 mm

DC Blocks for 5G Wireless Testing

JFW Model #ImpedanceTypeFrequency StartFrequency StopBreakdown VoltageRF Connectors
50DB-07650 OhmsInner100 MHz50 GHz75 Volts2.4 mm
50DB-07750 OhmsInner/Outer10 MHz40 GHz200 Volts2.9 mm
