19 Inch Rack RF Switch Assemblies (75 Ohm)
Below is a sortable table of 75 Ohm RF switch assemblies with 19 inch rack mount enclosures. JFW offers a wide selection of 75 Ohm RF switches (solid-state, electro-mechanical, reflective, absorptive) and we can integrate any of our RF switches into remotely controlled assembly.
Remote Control
Our test systems are available with Ethernet, Serial, or GPIB remote control. The remote control features easy to use ASCII formatted remote commands. All test systems with Ethernet/Serial control run out latest generation 3.x.x firmware. Use our Ethernet Test Box to demo the 3.x.x firmware.
JFW Model # | Impedance | Number of Switches | RF Switch Type | Frequency Start | Frequency Stop | RF Input Power | Control | RF Connectors |
---|---|---|---|---|---|---|---|---|
75SA-030 | 75 Ohm | 10 Switches | 1P4T Reflective | 5 MHz | 1000 MHz | +20 dBm | Keypad, Ethernet, RS-232 | F |
75SA-035 | 75 Ohm | 1 Switch | 1P8T Self-Terminating | DC | 1000 MHz | +20 dBm | Keypad, Ethernet, RS-232 | BNC, F |
75SA-053 | 75 Ohm | 1 Switch | 1P80T Self-Terminating | 45 MHz | 1003 MHz | +20 dBm | Keypad, Ethernet, RS-232 | F |
75SA-058 | 75 Ohm | 1 Switch | 1P16T Self-Terminating | 20 MHz | 1000 MHz | +20 dBm | Ethernet, RS-232 | F |
75SA-073 | 75 Ohm | 1 Switch | 1P50T Self-Terminating | DC | 1000 MHz | +27 dBm | Keypad, Ethernet, RS-232 | F |
75SA-081 | 75 Ohm | 2 Switches | 1P16T Self-Terminating | DC | 2150 MHz | +27 dBm | Keypad, Ethernet, RS-232 | F |
75SA-090 | 75 Ohm | 2 Switches | 1P6T Self-Terminating | 5 MHz | 1000 MHz | +10 dBm | Keypad, Ethernet, RS-232 | F |
Custom Models Available
If you do not find a model on the website that meets your requirements, please use our inquiry form or email our engineering department. We will respond with a quick cost estimate. JFW does not charge NRE fees for new models. A large portion of the RF test systems that we manufacture are per custom requests.
- Display 15 Products per page
-
Assembly with 1 RF Switch 1P16T 20-1000 MHz | 75SA-058 F
JFW Model #: 75SA-058
Impedance: 75 Ohm
Number of Switches: 1 Switch
RF Switch Type: 1P16T Self-Terminating
Frequency Range: 20-1000 MHz
RF Input Power: +20 dBm
Control: Ethernet, RS-232
RF Connectors: F female
Documentation: Data Sheet | Drawing -
Assembly with 1 RF Switch 1P50T DC-1000 MHz | 75SA-073 F
JFW Model #: 75SA-073
Impedance: 75 Ohm
Number of Switches: 1 Switch
RF Switch Type: 1P50T Self-Terminating
Frequency Range: DC-1000 MHz
RF Input Power: +27 dBm
Control: Manual, Ethernet, RS-232
RF Connectors: F
Documentation: Data Sheet | Drawing -
Assembly with 1 RF Switch 1P80T 45-1003 MHz | 75SA-053 F
JFW Model #: 75SA-053
Impedance: 75 Ohm
Number of Switches: 1 Switch
RF Switch Type: 1P80T Self-Terminating
Frequency Range: 45-1003 MHz
RF Input Power: +20 dBm
Control: Manual, Ethernet, RS-232
RF Connectors: F female
Documentation: Data Sheet | Drawing -
Assembly with 1 RF Switch 1P8T DC-1000 MHz | 75SA-035
JFW Model #: 75SA-035
Impedance: 75 Ohm
Number of Switches: 1 Switch
RF Switch Type: 1P8T Self-Terminating
Frequency Range: DC-1000 MHz
RF Input Power: +20 dBm
Control: Manual, Ethernet, RS-232
RF Connectors: BNC, F
Documentation: Data Sheet | Drawing -
Assembly with 10 RF Switches 1P4T 5-1000 MHz | 75SA-030 F
JFW Model #: 75SA-030
Impedance: 75 Ohm
Number of Switches: 10 Switches
RF Switch Type: 1P4T Reflective
Frequency Range: 5-1000 MHz
RF Input Power: +20 dBm
Control: Manual, Ethernet
RF Connectors: F female
Documentation: Data Sheet | Drawing -
Assembly with 2 RF Switches 1P16T DC-2150 MHz | 75SA-081 F
JFW Model #: 75SA-081
Impedance: 75 Ohm
Number of Switches: 2 Switches
RF Switch Type: 1P16T Self-Terminating
Frequency Range: DC-2150 MHz
RF Input Power: +27 dBm
Control: Manual, Ethernet, RS-232
RF Connectors: F female
Documentation: Data Sheet | Drawing -
Assembly with 2 RF Switches 1P6T 5-1000 MHz | 75SA-090 F
JFW Model #: 75SA-090
Impedance: 75 Ohm
Number of Switches: 2 Switches
RF Switch Type: 1P6T Self-Terminating
Frequency Range: 5-1000 MHz
RF Input Power: +10 dBm
Control: Manual, Ethernet, RS-232
RF Connectors: F female
Documentation: Data Sheet | Drawing
