Choosing the Right Programmable Attenuator for Receiver Sensitivity Tests

JFW’s own Bryan Walker had the privilege of being selected to be on the cover of the Microwave Journal (October 2023, Vol. 66, No. 10). Bryan’s article titled “Choosing the Right Programmable Attenuator for Receiver Sensitivity Tests” was the featured cover article that month.

Highlights of the article:

The article is currently available for viewing/download on the Microwave Journal website.

What is a step attenuator?April 25, 2024 - 11:44 am
A step attenuator is a variable attenuator that can have its attenuation setting varied over an attenuation range by a specific dB step size. All attenuation settings are referenced to the insertion loss. This means that the minimum setting (0dB) is the insertion loss state of the step attenuator. For example programmable attenuator model 50P-1857 […]
What is the use of a fixed attenuator?April 15, 2024 - 11:36 am
A fixed attenuator has two main uses: decrease signal power level, improve poor VSWR. A fixed attenuator is a passive device with internal resistors whose resistive values are calculated base on the impedance (50 Ohm or 75 Ohm) and the desired attenuation value. The attenuation value is expressed in terms of decibel (dB). When the […]
What is the difference between reactive and resistive power dividers?April 12, 2024 - 2:42 pm
Understanding the difference between reactive and resistive power dividers will help you create the best functionality for your RF testing setup. Their functionality is similar but yet different. Resistive Power Dividers Their construction is a star configuration. All ports are symmetrical. There is no common port with resistive type design. The star configurations functions as […]
